Description
Lubricated Plug Valve
Body: WCB, A105, LCB, LF2, WC6, F22, CF8, CF8M, F304, F316
Bonnet: WCB, A105, LCB, LF2, WC6, F22, CF8, CF8M, F304, F316
Plug: A105+ENP, Stainless Steel
Seat: PTFE
Seat Ring: PTFE
Packing: Graphite, PTFE
Gasket: Stainless Steel+Graphite
Bolts/Nut: B7/2H
Dimensions
Class | 150 | ||||||||||||||
mm | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 350 |
in | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 |
L-RF | 108 | 117 | 127 | 140 | 190 | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 | 381 |
L-BW | 152 | 178 | 203 | 216 | 229 | 267 | 305 | 330 | 356 | 381 | 394 | 457 | 533 | 610 | 686 |
H | 180 | 180 | 185 | 200 | 210 | 215 | 250 | 270 | 300 | 340 | 365 | 400 | 450 | 510 | 590 |
W | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 |
